Single Wire
Production Capacity
Double Wire
Production Capacity Per Month
Max.bending angle
Max.bending speed
Max. pulling speed
Mandrel diameter
Max.length of the stirrup side (diagonal)
Min. length of the stirrup side
Length tolerance
Bending tolerance
Avg. air-compressed consumption
Avg. electric power consumption
Labeled electric power
Voltage
Oerall machine weight
Overall dimension

:5-12 [mm]
:5-10 [mm]

:280-320 Tons with 10 hours x 2 shifts/ Day and 26 days/month
:180 [double direction
:1000 [*/sec]
:100 [m/mm]
:25-32
:1380
:120 [mm]
:1 [mm]
:1*
:6[1/mm]
:5[kw]
:25 [kw]
:415[v] - 50[hz]
:2, 600 [kg]
:8030 x 2005 x 2015 [mm]
